Board & Batten Siding, Done Right, for Lynden Homes

Board and batten has become one of the most requested siding profiles for homeowners in and around Lynden, and it's easy to see why. The vertical lines suit the farmhouse, craftsman, and modern-rural styles common on properties throughout this part of Whatcom County, and the deep shadow lines the profile creates give a home real dimension instead of a flat wall of siding. But board and batten is also one of the least forgiving profiles to install poorly. Every seam, every batten, every fastener line is a potential path for water if the details aren't right — and in this climate, water finds every mistake eventually.

This page is about that one job, done for Lynden homes specifically: what the local climate demands from a vertical siding system, what correct installation actually involves, and why we only put James Hardie fiber cement behind our board and batten work.

What Whatcom County Weather Does to Vertical Siding

Lynden sits inland from Bellingham Bay but still gets the marine layer's salt-laden air, along with the driving, wind-pushed rain that comes off the Strait and up the valley through the fall and winter. Add a long, damp moss season that can stretch from October through April, and you have three separate stresses working on a home's exterior at once: salt exposure that slowly attacks fasteners and finishes, wind-driven rain that gets pushed sideways into seams rather than falling straight down, and moisture that lingers in shaded, north-facing walls long enough for moss and algae to take hold.

Vertical board and batten reacts differently to this than horizontal lap siding does. Lap siding sheds water downward across overlapping courses. Board and batten relies on vertical seams and batten strips to keep water out, which means those seams are under constant pressure from wind-driven rain moving sideways instead of gravity pulling it straight down. If the seams, flashing, and fastening aren't detailed correctly, water gets pushed up and under the battens rather than running off the face — and once moisture gets behind the cladding, it doesn't dry out quickly in a Whatcom County winter.

Where Problems Actually Start

In our experience, board and batten failures almost never start with the board material itself — they start with:

• Batten fasteners driven directly through both the batten and the board into sheathing without accounting for expansion, causing splitting or fastener backout
• Missing or undersized gaps behind battens, which traps water instead of letting it drain
• No rainscreen gap, so the siding sits tight against the weather-resistive barrier with nowhere for incidental moisture to escape
• Butt joints and panel seams that aren't flashed or caulked to a real specification
• Bottom edges finished too close to grade, hardscape, or decking, so splashback keeps the lowest boards wet

Every one of these is a workmanship issue, not a material issue — which is why the crew doing the installation matters as much as the product going on the wall.

Why We Install James Hardie for Board & Batten — Not Vinyl, Not LP SmartSide, Not Cedar

We get asked regularly why we don't offer vinyl board and batten, LP SmartSide, or traditional cedar boards for this look, since all three are available and all three can be made to resemble the profile. Here's our honest answer.

Vinyl board and batten is inexpensive and low-maintenance in mild climates, but it's a poor match for driving coastal rain. Vinyl panels are designed to move with temperature swings, which means the seams and battens are never fully sealed — they rely on overlap and gravity, the same way lap siding does, which works against the vertical, wind-loaded water path this profile creates. In a climate with regular wind-driven rain, that gap tolerance becomes a liability rather than a feature.

LP SmartSide is an engineered wood product with a resin-treated strand core. It performs well in many climates, but it is still wood-based, which means cut edges, fastener penetrations, and seams need to stay sealed and coated for the life of the product. In a moss-prone, high-moisture region, any lapse in that maintenance — a missed caulk line, a scratch in the factory coating — gives moisture a path into a wood-based substrate. We don't think that's a fair trade to ask a Lynden homeowner to manage indefinitely.

Cedar board and batten is beautiful and it's a legitimate traditional choice, but it asks for real, ongoing upkeep: refinishing on a cycle, moisture monitoring, and vigilance against the moss and mildew that this climate practically guarantees on untreated or under-maintained wood. We'll install what a homeowner truly wants when they understand the trade-off, but as our standard, we don't recommend it here.

James Hardie fiber cement board and batten — typically HardiePanel vertical siding with HardieTrim battens, or the Artisan series for a more refined reveal — is non-combustible, dimensionally stable, and engineered specifically for wet, coastal-influenced climates through Hardie's HZ10 formulation for the Pacific Northwest. It doesn't swell, rot, or feed moss the way wood-based products can, and the factory-applied ColorPlus finish is baked on, not field-sprayed, which means better long-term color and edge performance in salt air and UV. That combination is why it's the only board and batten system we put our name behind.

What a Correct Board & Batten Installation Actually Involves

A board and batten job that's going to hold up in Lynden's weather isn't just "boards up, battens over the seams." Every layer behind the visible surface matters as much as the finish itself.

The Layers, From the Wall Out

1. Weather-resistive barrier — a continuous, properly lapped water barrier over the sheathing, with all penetrations sealed before any siding goes on.
2. Rainscreen gap — a furring or drainage mat layer that creates space between the barrier and the back of the siding, so any incidental moisture that gets past the surface can drain and the wall assembly can dry.
3. Flashing at every horizontal transition — window heads, water tables, roof-to-wall intersections, and butt joints all need metal or engineered flashing, not just caulk.
4. Hardie panel installation — panels fastened per Hardie's published fastening schedule, with correct edge clearance and gapping at panel-to-panel joints.
5. Battens — installed over the seams with the correct reveal and fastened in a way that allows for the material's normal expansion and contraction rather than pinning it rigidly.
6. Caulking and sealant — used at specified joints only, with a quality sealant rated for the exposure, not as a substitute for proper flashing.

Skipping the rainscreen gap is the single most common corner cut we see on board and batten re-sides in this region, because it doesn't show on day one — the wall looks finished either way. The difference shows up years later, in trapped moisture and premature failure at the sheathing level, long after the visible siding still looks fine.

Board & Batten Material Comparison for Whatcom County Homes

Material	Moisture & Moss Resistance	Maintenance	Typical Lifespan	Finish Durability
James Hardie fiber cement	Non-combustible, doesn't rot or feed moss; engineered for wet climates	Occasional wash; no refinishing under normal use	30+ years to warranty	Factory ColorPlus finish, resists fading and salt-air wear
Vinyl board & batten	Won't rot, but seams rely on overlap, not seal — vulnerable in wind-driven rain	Low, but can crack or warp in temperature swings	15-25 years	Color molded in, but can fade and chalk over time
LP SmartSide	Engineered wood core; performs well if coatings and seals stay intact	Requires maintained caulk lines and touch-up on cuts/damage	20-30 years with upkeep	Factory finish, but wood-based edges need vigilance
Cedar	Natural, but absorbs moisture and is prone to moss/mildew without upkeep	Periodic refinishing or staining required	20-40 years with diligent care	Field-applied finish wears fastest of the group

Our Process for Lynden Board & Batten Projects

We keep the process straightforward because homeowners deserve to know what's happening at each stage of a re-side.

• On-site assessment — we look at your current siding, sheathing condition, moisture history, and how water actually moves across your specific walls, since sun and wind exposure vary even within Lynden.
• Product and profile selection — HardiePanel with standard battens, or the Artisan series for a tighter, more refined reveal, along with ColorPlus color selection.
• Removal and substrate check — old siding comes off and we inspect sheathing for hidden rot or moisture damage before anything new goes up.
• Barrier, rainscreen, and flashing installation — the unglamorous work that determines whether the job lasts.
• Panel and batten installation — fastened and gapped to Hardie's specification, not shortcuts.
• Final inspection and cleanup — walkthrough with the homeowner and full site cleanup before we consider the job done.

Questions Worth Asking Any Contractor Bidding This Job

• Will you install a rainscreen gap, or is the siding going straight over the weather barrier?
• What is your batten fastening pattern, and does it allow for material expansion?
• How will you flash butt joints, window heads, and the bottom termination near grade?
• Are you a certified James Hardie installer, and can you show manufacturer-backed installation experience?
• What does your warranty cover — labor, or just the material?

Living With Board & Batten in a Moss-Prone Climate

Even the right material needs a little seasonal attention. Board and batten's vertical battens create narrow shadowed strips that hold moisture slightly longer than a flat wall, especially on north- and east-facing elevations that get less direct sun through Whatcom County's long grey stretch of fall and winter. A rinse-down once or twice a year, keeping gutters clear so runoff isn't sheeting down the wall face, and trimming back vegetation that shades the siding all go a long way toward keeping moss from establishing. Hardie's factory finish doesn't feed moss the way raw wood can, but nothing is immune to a Pacific Northwest damp season if water is allowed to sit against it indefinitely.

Why Hiring a Crew That Already Works Lynden Matters

Board and batten's clean, simple look hides a genuinely technical install. A crew that already works in Lynden and the surrounding Whatcom County area knows the local wind and rain patterns, understands how HOA and neighborhood aesthetics tend to run in this area, and isn't guessing at flashing details for the first time on your home. We're not a national outfit rotating through on a subcontracted schedule — we install one product system, we install it to the same standard on every job, and we're still local when you call us back with a question five years later.

Get a Free, No-Pressure Estimate

If you're considering board and batten siding for your Lynden home, we're happy to walk your property, look at your current siding and substrate condition, and give you an honest assessment of what the job actually needs — no pressure, no inflated scope. Use the form below to request a free estimate.
